Suzuki KingQuad 750AXi

Complete details of KingQuad 750AXi ATV


Suzuki KingQuad 750AXi is not yet available in India.

Rate Suzuki KingQuad 750AXi:
3.5/5 (2 votes)
Add To Compare
Write a Review
Suzuki KingQuad 750AXi Price

Not Available

Similar ATVs
Colours

Terra Green and Flame Red

Suzuki KingQuad 750AXi
Suzuki KingQuad 750AXi
Technical Specifications
Vehicle TypeATV
FuelPetrol
Engine Displacement722.00 cc
Engine Details4-stroke, liquid-cooled, single cylinder, DOHC
Engine StartingElectric
Bore x Stroke104.0mm x 85.0mm
Compression Ratio10.0 : 1
Engine LubricationWet sump
Fuel SystemSuzuki Fuel Injection
TransmissionCVT (V-belt), with high/low-range and reverse
Electricals
Battery
Brakes
Front BrakeDisc brakes, twin rotors
Rear BrakeSealed oil-bathed multi-disc
Chassis and Suspension
Frame
Front SuspensionIndependent, double wishbone, coil spring, oil damped with five-way preload adjustable shock absorbers
Rear SuspensionIndependent, double wishbone, coil spring, oil damped with five-way preload adjustable shock absorbers
Tyres
Wheels / Rim
Front TyreAT25 x 8-12, tubeless type x 2
Rear TyreAT25 x 10-12, tubeless type x 2
Dimensions
Length x Width x Height2115 x 1210 x 1245 mm
Wheelbase1280 mm
Weight302 kg
Ground Clearance270 mm
Petrol Tank Capacity17.5 litres
