Raven
| Vehicle Type | Motorcycle |
| Fuel | Petrol |
| Engine Displacement | 1304.00 cc |
| Engine Details | Liquid-cooled, 4-stroke, SOHC, 4-valve, V-twin |
| Engine Starting | Electric |
| Bore x Stroke | 100mm x 83mm |
| Compression Ratio | 9.5 : 1 |
| Engine Lubrication | Wet sump |
| Fuel System | Fuel Injection |
| Ignition | TCI |
| Cooling System | Liquid Cooled |
| Transmission | Constant mesh 5-speed |
| Gear Shift Pattern | 1-N-2-3-4-5 |
| Brakes | |
|---|---|
| Front Brake | 320 mm Hydraulic single disc |
| Rear Brake | 310 mm Hydraulic single disc |
| Chassis and Suspension | |
|---|---|
| Frame | Double cradle |
| Front Suspension | 135 mm Telescopic forks |
| Rear Suspension | 100 mm Swingarm (link suspension) |
| Tyres | |
|---|---|
| Wheels / Rim | Cast Aluminium Wheels |
| Front Tyre | 120/70-21M/C 62H Tubeless |
| Rear Tyre | 210/40R18M/C 73H Tubeless |
| Dimensions | |
|---|---|
| Length | 2530 mm |
| Width | 860 mm |
| Height | 1130 mm |
| Wheelbase | 1750 mm |
| Weight | 293 kg |
| Ground Clearance | 150 mm |
| Fuel Tank Capacity | 15 litres |
